Tilting Scooter - Free Plan Details
WHEELS
Click on Drawing Images - Password is:
scooter
10" pneumatic wheels
are used both front and rear.
The rear drive
wheels are modified slightly to accept a torque plate to
secure them to the drive box axles.
The front wheel
carries a standard bike brake disc.
Each drawing sheet
shows the construction and parts for each of these
modification and includes the required list of bought
and made parts.
External, sectional
and isometric views are again used to illustrate the
modifications and attachments.
